The information in the chart below can be used to assist with the identification of the most appropriate coupler. For more detailed information please select a range from the menu.
Please note, this section is subject to change and you are advised to contact your local sales office to discuss any project-specific requirements.
Reinforcing Bar Couplers (PDF, 8.14 MB)
|Type||Standard Coupler||Headed Anchor||KSN Anchor|
|Bar Dia. mm||12-40||12-40||12-20|
|Bar End Prep||Threaded||Threaded||Threaded|
|Product Code||RT12-40||RTHA12-40||RTKSN12-20 S/M/L|
|Bar Dia. mm||12-40||12-40||12-40|
|Bar End Prep||No||No||No|
|Assembly Tool||Wrench or *Nut Runner|
*Although larger 25-40mm sizes can be tightened using a hand ratchet wrench, we recommend the use of an electric or pneumatic wrench designed to deliver a steady tightening force to the bolts.
